… tings Contents Overview 04 FOR S IN GLE LE A F SI N G LE A N D D O U B LE-ACTI O N DO O R S TS 500 NV 08 TS 500 N EN3 14 TS 550 NV 20 TS 550 NV F 26 ACC ES S OR IES Accessories for floor springs 34 RSZ … Floor springs andglass clamping fit tings | Overview TS 500 N EN … Floor springs andglass clamping fit tings | For single leaf single and double-action doors | TS 500 NV TS 500 NV Floor spring for single leaf single and double-action doors of up to 1100 mm leaf width with adjustable closing force EN 1-4 and with optional hold-open function ARE AS OF APPLI CATI O N Fire and smoke protection doors Right and left single- and double-action doors Single- and double-action doors up to 1100 mm leaf width and 150 kg weight Hidden horizontal floor installation PR OD U CT FE AT U R ES Adjustable closing force of EN1-4 Can be used for right and left hand doors without conversion Closing speed can be individually adjusted Hydraulic latching action which accelerates the door shortly before the closed position Integrated back check, slows down doors that are thrown open forcefully All functions can be adjusted from the top and when installed V E R S ION S TS 500 NV with hold-open function: mechanical hold-open function in door closer with hold-open area of 85°/90°/105°/120° for single-action doors and hold-open area of 90°/95°/110°/125° for double-action doors (not permissible for use on fire and smoke protection doors) TS 500 NV | For single leaf single and double-action doors | Floor springs andglass clamping fi t tings TEC HN ICAL DATA FO R F LO O R SP R I N G S TS 500 NV TS 500 NV with hold-open function yes no PRODUCT FEATURES Suitability for fire protection doors Use on single-action/double-action door single-action door, double-action door Barrier-free in accordance with DIN 18040 up to leaf width (max.) in mm 1100 mm - Type of installation floor Opening angle (max.) 170° Closing force acc. to EN 1154 EN … Floor springs andglass clamping fit tings | For single leaf single and double-action doors | TS 500 NV PRODU CT S CALE D R AW I N G 42 TS … N V 278 298 36-46 36-46 82 105 51-61 STAN DA R D IN STALLAT I O N Example of door rail, upper pivot and floor spring installation on a single-action door (aluminium): A-A 36 B-B 51 A A 36 278 B H S 82 B 42 10 Door rail model DB, EK, FK for single-action doors H = Installation height dimension With elongated pivots, the installation height dimension "H" is increased by the respective spindle extension Model S H DB, EK, FK 10 mm 24 mm TS 500 NV | For single leaf single and double-action doors | Floor springs andglass clamping fi t tings Example of door rail, upper pivot and floor spring installation on a double-action door: C A A-A 175 … = Cover plates - cap shortened | OKFF = Finished floor level Door rail model CM, C for double-action doors With elongated pivots, the installation height dimension "H" is increased by the respective spindle extension Model S H CM 19 mm 29 mm C 19 mm 29 mm 11 12 Floor springs andglass clamping fit tings | For single leaf single and double-action doors | TS 500 NV TS 500 N V – OR D E R I N FO R MAT I O N Designation TS 500 NV door closer Size EN 1-4, optionally with fixed mechanical hold-open function (without cover plate and accessories) DIN Direction Hold-open single action Hold-open double-action Version left/right 0° 0° silver-coloured 102084 left/right 85° 90° silver-coloured 103974 ID no. left/right 90° 95° silver-coloured 104028 left/right 105° 110° silver-coloured 104029 left/right 120° 125° silver-coloured 104030 Floor spring cover plate for TS 500 NV / TS 500 N EN3 brass 103012 stainless steel 102127 TS 500 N V – OR D E R I N FO R MAT I O N Designation DIN Direction Spindle extension Version ID no. left stainless steel optic 137586 left EV1 006794 right stainless steel optic 137577 right EV1 006798 left stainless steel optic 137618 left EV1 045196 right stainless steel optic 137617 right EV1 045155 Cover caps for pivot hinges (flush-mounted doors) suitable for models DB, EK, FK left/right EV1 001090 left/right stainless steel optic 137640 Cover caps for pivot hinges (rebated doors) suitable for models DB, EK, FK left stainless steel optic 137641 left EV1 037918 right EV1 038302 right stainless steel optic 137642 ACCESSORIES Cover caps for door rails (flush-mounted doors) suitable for models DB, EK, FK Cover caps for door rails (rebated doors) suitable for models DB, EK, FK Spindle cap for floor spring … mm 053315 TS 500 NV | For single leaf single and double-action doors | Floor springs andglass clamping fi t tings TS … It may be necessary to use a longer pivot depending on the installation situation. This is a simple process for all floor-mounted door closer versions in the TS 500 NV/TS 550 NV series by unscrewing the standard pivot and attaching the longer pivot. *For more detailed information about the combination options see page 35 ff. 13 14 Floor springs andglass clamping fit tings | For single leaf single and double-action doors | TS 500 N EN3 TS 500 N EN3 Floor spring for single leaf single and double-action doors of up to 950 mm leaf width with fixed closing force EN3 and with optional hold-open function ARE AS OF APPLI CATI O N Fire and smoke protection doors Right and left single- and double-action doors Single- and double-action doors up to 950 mm leaf width and 100 kg weight Hidden horizontal floor installation PR OD U CT FE AT U R ES Fixed closing force of EN3 Can be used for right and left hand doors without conversion Closing speed can be individually adjusted Hydraulic latching action which accelerates the door shortly before the closed position Integrated back check, slows down doors that are thrown open forcefully All functions can be adjusted from the top and when installed V E R S ION S TS 500 N EN3 with hold-open function: with fixed closing force of EN3 and mechanical hold-open function in the door closer with hold-open area of 85°/90°/105°/120° for single-action doors and hold-open area of 90°/95°/110°/125° for double-action doors (not permissible for use on fire and smoke protection doors) TS 500 N EN3 | For single leaf single and double-action doors | Floor springs andglass clamping fi t tings TEC HN ICAL DATA FO R F LO O R SP R I N G S PRODUCT FEATURES Headline 30Pt neg undo from template Suitability for fire protection doors Use on single-action/double-action door TS 500 N EN3 TS 500 N EN3 with hold-open function yes no single-action door, double-action door Barrier-free in accordance with DIN 18040 up to leaf width (max.) in mm 950 mm Type of installation floor Opening angle (max.) 170° Closing force acc. to EN 1154 EN … = Frontal gearing pivot 15 Floor springs andglass clamping fit tings | For single leaf single and double-action doors | TS 500 N EN3 PRO D U CT S CALE D R AW I N G 42 TS 500 N EN … 278 298 36-46 36-46 82 105 51-61 STAN DA R D IN STALLAT I O N Example of door rail, upper pivot and floor spring installation on a single-action door (aluminium): A-A 36 B-B 51 A A 36 278 B H S 82 B 42 16 Door rail model DB, EK, FK for single-action doors H = Installation height dimension With elongated pivots, the installation height dimension "H" is increased by the respective spindle extension Model S H DB, EK, FK 10 mm 24 mm TS 500 N EN3 | For single leaf single and double-action doors | Floor springs andglass clamping fi t tings Example of door rail, upper pivot and floor spring installation on a double-action door: C A A-A 175 … = Cover plates - cap shortened | OKFF = Finished floor level Door rail model CM, C for double-action doors With elongated pivots, the installation height dimension "H" is increased by the respective spindle extension Model S H CM 19 mm 29 mm C 19 mm 29 mm 17 18 Floor springs andglass clamping fit tings | For single leaf single and double-action doors | TS 500 N EN3 TS 500 N E N … mm 053315 TS 500 N EN3 | For single leaf single and double-action doors | Floor springs andglass clamping fi t tings TS … It may be necessary to use a longer pivot depending on the installation situation. This is a simple process for all floor-mounted door closer versions in the TS 500 NV/TS 550 NV series by unscrewing the standard pivot and attaching the longer pivot. *For more detailed information about the combination options see page 35 ff. 19 20 Floor springs andglass clamping fit tings | For single leaf single and double-action doors | TS 550 NV TS 550 NV Floor spring for single leaf single and double-action doors of up to 1400 mm leaf width with adjustable closing force EN 3-6 and with hold-open function that can be switched on and off ARE AS OF APPLI CATI O N Right and left single- and double-action doors Single- and double-action doors up to 1400 mm leaf width and 300 kg weight Highly frequented and heavy doors Hidden horizontal floor installation PR OD U CT FE AT U R ES Closing force of EN3-6 with variable adjustment Can be used for right and left hand doors without conversion Adjustable delayed closing action, for adjusting the closing speed of the door up to an opening angle of approx. 80° Mechanical hold-open function in door closer with hold-open area of 85°-165° Hydraulic latching action which accelerates the door shortly before the closed position Closing speed can be individually adjusted Integrated back check, slows down doors that are thrown open forcefully All functions can be adjusted from the top and when installed TS 550 NV | For single leaf single and double-action doors | Floor springs andglass clamping fi t tings T EC H N I CAL DATA F O R F L O O R S P R I N G S TS 550 NV PRODUCT FEATURES Use on single-action/double-action door single-action door/double-action door Closing force acc. to EN 1154 EN … = Frontal gearing pivot 21 Floor springs andglass clamping fit tings | For single leaf single and double-action doors | TS 550 NV PRO D U CT S CALE D R AW I N G 54 1,5 TS … 50 N V 342 362 36 82 105 36 51-60 STAN DA R D IN STALLAT I O N Example of door rail and floor spring installation on a single-action door (aluminium): A-A B 36 30 B-B A A 54 36 51 82 342 B H S 22 Door rail model DB, EK, FK for single-action doors H = Installation height dimension With elongated pivots, the installation height dimension "H" is increased by the respective spindle extension Model S H DB, EK, FK 10 mm 24 mm TS 550 NV | For single leaf single and double-action doors | Floor springs andglass clamping fi t tings Example of door rail, upper pivot and floor spring installation on a double-action door: A-A C A 175 … = Cover plates - cap shortened | OKFF = Finished floor level Door rail model CM, C for double-action doors With elongated pivots, the installation height dimension "H" is increased by the respective spindle extension Model S H CM 19 mm 29 mm C 19 mm 29 mm 23 24 Floor springs andglass clamping fit tings | For single leaf single and double-action doors | TS 550 NV TS 55 … mm 053957 left 10 mm 053958 right 10 mm 053959 left 15 mm 053960 right 15 mm 053961 left 20 mm 053962 right 20 mm 053963 left 25 mm 053964 right 25 mm 053965 TS 550 NV | For single leaf single and double-action doors | Floor springs andglass clamping fi t tings TS … It may be necessary to use a longer pivot depending on the installation situation. This is a simple process for all floor-mounted door closer versions in the TS 500 NV/TS 550 NV series by unscrewing the standard pivot and attaching the longer pivot. *For more detailed information about the combination options see page 35 ff. 25 26 Floor springs andglass clamping fit tings | For single leaf single and double-action doors | TS 550 NV F TS 550 NV F Floor spring for single leaf doors up to 1400 mm leaf width with hold-open function that can be switched on and off ARE AS OF APPLI CATI O N Fire and smoke protection doors Right and left single- and double-action doors Single- and double-action doors up to 1400 mm leaf width and 300 kg weight Highly frequented and heavy doors Hidden horizontal floor installation PR OD U CT FE AT U R ES Closing force of EN3-6 with variable adjustment Can be used for right and left hand doors without conversion Adjustable delayed closing action, for adjusting the closing speed of the door up to an opening angle of approx. 80° Hydraulic latching action which accelerates the door shortly before the closed position Closing speed can be individually adjusted Integrated back check, slows down doors that are thrown open forcefully All functions can be adjusted from the top and when installed TS 550 NV F | For single leaf single and double-action doors | Floor springs andglass clamping fi t tings T EC H N I CAL DATA F O R F L O O R S P R I N G S TS 550 NV F PRODUCT FEATURES Use on single-action/double-action door single-action door Closing force acc. to EN 1154 3–6 Leaf width recommended up to 1400 mm Leaf weight (max.) 300 kg Door stop DIN direction left/right Product tested in accordance with door closer tested acc. to EN 1154 Length 342 mm Overall depth 82 mm Height 54 mm Length adjustment range for cement box … = Frontal gearing pivot 27 Floor springs andglass clamping fit tings | For single leaf single and double-action doors | TS 550 NV F PRO D U CT S CALE D R AW I N G 54 1,5 TS … 50 N V F 342 362 36 82 105 36 51-60 STAN DA R D IN STALLAT I O N Example of door rail and floor spring installation on a single-action door (aluminium): B-B B 30 A-A 36 A A 54 36 82 51 342 B H S 28 Door rail model DB, EK, FK for single-action doors H = Installation height dimension With elongated pivots, the installation height dimension "H" is increased by the respective spindle extension Model S H DB, EK, FK 10 mm 24 mm TS 550 NV F | For single leaf single and double-action doors | Floor springs andglass clamping fi t tings TS … mm 050930 left/right 10 mm 010338 left/right 13 mm 052170 left/right 15 mm 010347 left/right 20 mm 010372 left/right 25 mm 010373 left/right 28 mm 050931 left/right 30 mm 010374 left/right 35 mm 010377 left/right 40 mm 010378 left/right 45 mm 010381 left/right 50 mm 010385 29 30 Floor springs andglass clamping fit tings | For single leaf single and double-action doors | TS 550 NV F TS 55 … Only permissible for fire and smoke protection doors when this use is included in the approval certificate for the door. *For more detailed information about the combination options see page 35 ff. TS 550 NV F | For single leaf single and double-action doors | Floor springs andglass clamping fi t tings TS 550 NV F, HafenCity University, Hamburg, Germany (photo: Stefan Dauth) 31 32 33 SW ING D O ORS Accessories To make your hold-open devices even safer in an emergency, we have a wide range of accessories in our product range. For example, you can opt for a GEZE smoke switch control unit. Manual or wireless – we have numerous versions on offer for you. We are more than happy to answer any questions you may have about your safe door. Floor springs andglass clamping fit tings | Accessories | TS 137b / TS 32 b floor-mounted pivot bearingand cover plate TS 137b / TS 32 b floor-mounted pivot bearing and cover plate … mm silver-coloured 010564 stainless steel 012846 Cover plate for floor-mounted pivot bearing for type TS 137 b and TS 32 b Door rail and pivot hinge for single-action doors | Accessories | Floor springs andglass clamping fi t tings Door rail and pivot hinge for single-action doors 10 19 D OOR R A IL A N D P I VOT H I N G E D B FO R S I N G LE-ACTI O N DO O R S 217 45 48 48 48 24 48 52 33 Door rail model DB … 24 Standard version with 45 mm pivot pin. 41 mm and 49 mm pivot pins must be ordered separately. 35 36 Floor springs andglass clamping fit tings | Accessories | TS Door 137b rail/and TS 32 pivot b floor-mounted hinge for single pivot action bearingand doors cover plate D OO R R A IL A N D P I VOT H I N G E D B FO R S I N G LE-ACTI O N DO O R S – O RDER I N FO RMATI O N Version ID no. Door rail for single-action doors Model DB, for rebated & flush-mounted metal and timber doors ¹ Designation flat cone galvanised 044579 square galvanised 037581 Pivot hinge for single-action doors Model DB, for rebated & flush-mounted metal and timber doors ¹ combination a galvanised 044676 combination b DIN left galvanised 044697 combination b DIN right galvanised 044680 combination c galvanised 044787 … standard length of pivot pin = 45 mm Door rail and pivot hinge for single-action doors | Accessories | Floor springs andglass clamping fi t tings Door rail and pivot hinge for single-action doors 19 10 D OOR R A IL A N D P I VOT H I N G E E K FO R SI N G LE-ACTI O N DO O R S 35 36 33 Door rail model EK … Door rail model EK 33 38,5 S 36 b S c Pivot hinge model EK Pivot hinge model EK IN STALLATION D I M E N S I O N S CO MBI N AT I O N a b c Dimension = S S S Pivot pin 41 mm without intermediate ring 41 27 13 Pivot pin 45 mm without intermediate ring 45 31 17 Pivot pin 49 mm without intermediate ring 49 35 21 Standard version with 45 mm pivot pin. 41 mm and 49 mm pivot pins must be ordered separately. 37 38 Floor springs andglass clamping fit tings | Accessories | Door rail and pivot hinge for single-action doors D OO R R A IL A N D P I VOT H I N G E E K FO R SI N G LE-ACTI O N DO O RS – O R DER I N FO R MATI O N Version ID no. Door rail for single-action doors Model EK, for welding to steel doors … standard length of pivot pin = 45 mm Door rail and pivot hingefor single-action doors | Accessories | Floor springs andglass clamping fi t tings Door rail and pivot hinge for single-action doors 10 19 D OOR R A IL A N D P I VOT H I N G E F K FO R SI N G LE-ACTI O N DO O R S 35 78 33 Door rail model FK S 19,5 a … 40 S 78 b 33 S c Pivot hinge model FK Pivot hinge model FK IN STALLATION D I M E N S I O N S CO MBI N AT I O N a b c Dimension = S S S Pivot pin 41 mm without intermediate ring 41 28 15 Pivot pin 45 mm without intermediate ring 45 32 19 Pivot pin 49 mm without intermediate ring 49 36 23 Standard version with 45 mm pivot pin. 41 mm and 49 mm pivot pins must be ordered separately. 39 40 Floor springs andglass clamping fit tings | Accessories | Door rail and pivot hingefor single-action doors D OO R R A IL A N D P I VOT H I N G E F K FO R SI N G LE-ACTI O N DO O R S – O RDER I N FO RMATI O N Version ID no. Door rail for single-action doors Model FK, for welding for steel doors … standard length of pivot pin = 45 mm Cover caps for door rails (flush-mounted and rebated doors) | Accessories | Floor springs andglass clamping fi t tings Cover caps for door rails (flush-mounted and rebated doors) 25 SU ITAB LE FOR M O D E LS D B, E K , F K 76 36 32 R 25 Cover cap, right Cover caps for door rail models DB, EK, FK COV E R CAP S FO R D O O R R A I LS – O R D ER I N FO RMATI O N Designation DIN/ISO direction Version ID no. Cover caps for door rails (flush-mounted doors) suitable for models DB, EK, FK left stainless steel optic 137586 left EV1 006794 right stainless steel optic 137577 right EV1 006798 left stainless steel optic 137618 left EV1 045196 right stainless steel optic 137617 right EV1 045155 Cover caps for door rails (rebated doors) suitable for models DB, EK, FK ¹ … The cover caps for the door rails and the pivot hinge lower part are ground by 14 mm for installation on rebated doors. 41 Floor springs andglass clamping fit tings | Accessories | Cover caps for pivot hinges (flush-mounted and rebated doors) Cover caps for pivot hinges (flush-mounted and rebated doors) 23 SU ITA B LE FOR M O D E LS D B, E K , F K 23 47 … The cover caps for the door rails and the pivot hinge lower part are ground by 14 mm for installation on rebated doors. Door rails for double-action doors | Accessories | Floor springs andglass clamping fi t tings Door rails for double-action doors M OD E LS CM , C A N D S 60 A 33,2 10 19 232,2 A-A Door rail model CM 30 30 60 60 55 24 30 20 19 10 6,5 Ø 12 22,5 Door rail model C 90° Door rail model C 125 … 30 25 Ø 30 Door rail model S Door rail model S A 43 44 Floor springs andglass clamping fit tings | Accessories | Cover caps for pivot hinges (flush-mounted and rebated doors) D OO R R A ILS FOR D O U B LE-ACT I O N D O O R S – O R DER I N FO R MATI O N Designation Version ID no. Door rail for double-action doors Model CM, for metal doors, on-site adaptation to profile system, without surface treatment galvanised 021817 Door rail for double-action doors Model CM, for metal doors, adapted to profile system ¹ flat cone galvanised 001067 Door rail for double-action doors Model C, for metal and timber doors flat cone galvanised 007432 Door rail for double-action doors Model S, for welding to steel doors flat cone phosphated 007434 … The profile system and profile combination used must be specified with the order. Adjustable pivot hinge for double-action doors | Accessories | Floor springs andglass clamping fi t tings Adjustable pivot hinge for double-action doors M OD E LS B A N D C, S U I TA B LE FO R D O O R R AI LS C, CM, S 10 23 25 … 5 23 175 36 - 58 25 94 140 Adjustable pivot hinge model C Adjustable pivot hinge model C ADJU STA B LE P I VOT H I N G E , C OV E R PA N EL AN D FR O N T PAN EL FO R DO UBLE-ACTI O N DO ORS – O R D E R IN FOR MAT I O N Designation Pivot pin Version ID no. Adjustable pivot hinge for double-action doors Model B, suitable for C, CM, S door rails pivot pin 43 mm galvanised 006371 pivot pin 55 mm galvanised 000108 pivot pin 65 mm galvanised 000903 pivot pin 43 mm galvanised 006666 pivot pin 55 mm galvanised 000905 pivot pin 65 mm galvanised 000904 Adjustable pivot hinge for double-action doors Model C, suitable for C, CM, S door rails 45 46 Floor springs andglass clamping fit tings | Accessories | RSZ … smoke switch control unit | Accessories | Floor springs andglass clamping fi t tings PR OD U CT S CALE D R AW I N G 347 293 27 124 33 30 14 55 … Surcharge for RAL special colours, see General notes in the price list. 120503 alpine white/red 120880 010994 47 48 49 SW ING D O ORS Glass clamping fittings Glass doors are popular – they provide perspective and have a timeless design. Glass clamping fittings should also fit in harmoniously. GEZE Glass Fittings will win you over with their conservative appearance and diversity. Depending on your interior, you can choose between surfaces made from satined and polished stainless steel. And to ensure that transparency is not at the expense of safety, we have lockable glass clamping fittings to meet your special needs – locks with strike boxes. 50 Floor springs andglass clamping fit tings | Glass clamping fittings | GEZE Glass Fittings GEZE Glass Fittings GEZE Glass Fittings ARE AS OF APPLI CATI O N For indoor and outdoor systems For single-action and double-action doors For static all-glass systems For toughened safety glass For glass thicknesses 10 and 12 mm Door leaf weights of up to 100 kg Suitable for single and double leaf swing doors PR OD U CT FE AT U R ES Elegant cover caps made of polished or brushed stainless steel Problem-free adjustment for glass thicknesses of 10 – 12 mm GEZE Glass Fittings | Glass clamping fittings | Floor springs andglass clamping fi t tings TEC HN ICAL DATA G LASS F I TT I N G S GEZE Glass Fittings PRODUCT FEATURES Design depth irrespective of thickness of glass 32 mm Variable pivot point with double-action doors 53 and 63 mm Tightening torques of the clamping screws … Nm Burglar-resistant installation of the door fitting / insert ● Shims for glass thicknesses 10 and 12 mm delivered by GEZE Door leaf height max. 2800 mm Door leaf width max. 1000 mm Door leaf weight max. 100 kg Floor springs that can be used with flat conical spindle– TS TS 500 NV / TS 550 NV Locks prepared for profile cylinders EURO-PZ 30/30 ● = yes STA N DA R D IN STALLAT I O N Example of installation without fanlight PT24 PT24 PT24 PT24 PT20 PT20 PT20 PT20 US50 PT20 GK50 PL50 PT10 PT24 US50 PT10 TS 500 NV / TS 550 NV PL55 PL50 TS 500 NV / TS 550 NV PT10 PT10 TS 500 NV / TS 550 NV TS 500 NV / TS 550 NV PT10 US50 TS 500 NV / TS 550 NV Example of installation with fanlight PT84 PT30 PT63 US50 PT10 PL50 TS 500 NV / TS 550 NV PL50 PL50 US50 GK50 PT40 PT40 GK50 PT20 PT20 US50 PT10 PT10 US50 TS 500 NV / TS 550 NV TS 500 NV / TS 550 NV GK20 PT40 PT20 PT20 PT10 TS 500 NV / TS 550 NV GK50 PL55 PL50 51 52 Floor springs andglass clamping fit tings | Glass clamping fittings | Corner fittings and pivot bearings Corner fittings and pivot bearings PT 10 - LOW E R S W I N G LE A F C O R N E R F I TT I N G PT 20 - U PP E R S W I N G LE A F C O R N E R F I TT I N G PT 24 - U PP E R P I VOT W I T H P I VOT B E A R I N G BO LT Corner fittings and pivot bearings | Glass clamping fittings | Floor springs andglass clamping fi t tings PT 21 – U PP E R P I VOT B E A R I N G W I T H S CR EW- O UT PI VOT BEAR I N G BO LT 175 … 4 53/63 60 53 54 Floor springs andglass clamping fit tings | Glass clamping fittings | Corner fittings and pivot bearings ORD E R IN FOR MAT I O N Designation Version ID no. GEZE Glass Fitting PT 10 Bottom side-hung leaf corner fitting with mount for flat conical spindle with installation materials for glass thicknesses 10 and 12 mm matt stainless steel 169752 polished stainless steel 180438 GEZE Glass Fitting PT 20 Top side-hung leaf corner fitting with mount for pivot bearing bolts (15 mm dia.) with installation materials for glass thicknesses 10 and 12 mm matt stainless steel 169763 polished stainless steel 180439 GEZE Glass Fitting PT 24 Upper pivot bearing with pivot bearing bolt (15 mm dia.) and screw platewith installation materials matt stainless steel 169774 polished stainless steel 180489 PT 21 Top pivot bearing with screw-out pivot bearing bolts galvanised 010739 DL-FL Floor-mounted pivot bearing with flat tapered bolts (FL) stainless steel 135393 DL-RD Floor-mounted pivot bearing with round bolts (RD) stainless steel 135555 stainless steel 146396 ACCESSORIES DL-FL cover plate Cover plate for concealed installation of the DL-FL with … mm floor level clearance of the side-hung leaf Fanlight and connecting fittings | Glass clamping fittings | Floor springs andglass clamping fi t tings Fanlight and connecting fittings PT … 4 - C ON N ECT I N G F I TT I N G S FO R G LASS- WALL AN D G LASS- CEI LI N G (DO UBLE) 55 56 Floor springs andglass clamping fit tings | Glass clamping fittings | Fanlight and connecting fittings PT 90 - C ON N ECT I N G F I TT I N G S FO R G LASS- WALL AN D G LASS- CEI LI N G (SI N G LE) PT 63 - B R AC K E T A N D C O R N E R C O N N ECT I N G FI TTI N G W I TH DO O R STO P PT 24 - U PP E R P I VOT W I T H P I VOT B E A R I N G BO LT Fanlight and connecting fittings | Glass clamping fittings | Floor springs andglass clamping fi t tings OR D E R IN FORMAT I O N Designation Version ID no. GEZE Glass Fitting PT 30 Fanlight fitting with pivot bearing bolts (15 mm dia.) and wall attachment accessories with installation materials for glass thicknesses 10 and 12 mm matt stainless steel 169764 polished stainless steel 180440 GEZE Glass Fitting PT 40 Angle fanlight fitting with pivot bearing bolt (15 mm dia.) with installation materials for glass thicknesses 10 and 12 mm matt stainless steel 169765 polished stainless steel 180441 GEZE Glass Fitting PT 84 Connecting fittings for glass-wall/glass-ceiling (double) with installation materials for glass thicknesses 10 and 12 mm matt stainless steel 169766 polished stainless steel 180482 GEZE Glass Fitting PT 90 Connecting fitting for glass-wall/glass-ceiling (single) with installation materials for glass thicknesses 10 and 12 mm matt stainless steel 169767 polished stainless steel 180483 GEZE Glass Fitting PT 63 Bracket/corner connecting fitting with door stop with installation materials for glass thicknesses 10 and 12 mm matt stainless steel 169768 polished stainless steel 180484 GEZE Glass Fitting PT 24 Upper pivot bearing with pivot bearing bolt (15 mm dia.) and screw plate with installation materials matt stainless steel 169774 polished stainless steel 180489 IS-BS Door stop insert for PT 30 / 40 black 135105 IS-BLK Blind insert for PT 30 / 40 matt stainless steel 135349 polished stainless steel 135106 ACCESSORIES 57 58 Floor springs andglass clamping fit tings | Glass clamping fittings | Locks and strike boxes Locks and strike boxes PL 55 - FITTIN G FO R MA N UAL LO C K I N G D E VI CE , W I TH R O UN D BO LTS U S 50 R D - LOC K I N G F I TT I N G C E N T R E LO CK W I TH R O UN D BO LT U S 50 - LOC K IN G F I TT I N G C E N T R E LO C K W I TH SQUARE BO LT Locks and strike boxes | Glass clamping fittings | Floor springs andglass clamping fi t tings PL … 0 - ST R IK E B OX FO R LO C K I N G F I TTI N G CEN TR E LO CK 46,5 59 60 Floor springs andglass clamping fit tings | Glass clamping fittings | Locks and strike boxes GK 20 - FA N L IGH T ST R I K E B OX ( D O U B LE ) FO R TWO CO RN ER LO CK FI TTI N G S 46,5 ORD E R IN FOR MAT I O N Designation Version ID no. matt stainless steel GEZE Glass Fitting PL 55 Fitting for manual locking device, with round bolts with installation materials for glass thicknesses 10 and 12 mm, with Euro profile cylin- polished stainless steel der and strike plate / recess 169769 matt stainless steel GEZE Glass Fitting US 50 RD Lock fitting central lock with round bolt with installation materials for glass thicknesses 10 and 12 mm, with Euro profile cylin- polished stainless steel der and strike plate / recess 169770 matt stainless steel GEZE Glass Fitting US 50 Lock fitting centre lock with flat bolt with installation materials for glass thicknesses 10 and 12 mm, with Euro profile cylin- polished stainless steel der and strike plate / recess 169776 matt stainless steel GEZE Glass Fitting PL 50 RD Lock fitting corner lock with round bolt with installation materials for glass thicknesses 10 and 12 mm, with Euro profile cylin- polished stainless steel der and strike plate / recess 169775 matt stainless steel GEZE Glass Fitting PL 50 Lock fitting centre lock with flat bolt with installation materials for glass thicknesses 10 and 12 mm, with Euro profile cylin- polished stainless steel der and strike plate / recess 169777 180485 180486 180491 180490 180492 GEZE Glass Fitting GK 50 Strike boxes for locking fitting central lock with installation materials for glass thicknesses 10 and 12 mm matt stainless steel 169772 polished stainless steel 180488 GEZE Glass Fitting GK 20 Fanlight strike box (double) for two corner lock fittings with installation materials for glass thicknesses 10 and 12 mm matt stainless steel 169771 polished stainless steel 180487 GEZE Glass Fitting Round bolt strike Locking recess for lock fittings with round bolts with installation materials matt stainless steel 169778 polished stainless steel 180493 GEZE Glass Fitting Square bolt strike Strike plate for locking fittings with flat bolt with installation materials matt stainless steel 169779 polished stainless steel 180494 ACCESSORIES Locks and strike boxes | Glass clamping fittings | Floor springs andglass clamping fi t tings Installation situation (photo: GEZE GmbH) 61 62 63 SW ING D O ORD Modular fixed panel profile systems The clip-on aluminium cover profile can easily be replaced without changes to the basic system. This is made possible by the clamping plates that can be freely positioned in the profile and which adjust to all glass thicknesses. Construction components outside of the system such as glazing blocks to calibrate the glass panes art required because the relevant calibration units are integrated within the clamping system. This simplifies installation, reduces stocks and increases safety. The clamping screws on the clamping plate are screwed into the freely positionable threaded nuts which secures them against unauthorised removal. 64 Floor springs andglass clamping fit tings | Modular fixed panel profile systems | Fixed panel profile with clip-on cover profile design 40 Fixed panel profile with clip-on cover profile design 40 Modular fixed panel profile with clip-on cover profile design 40 ARE AS OF APPLI CATI O N For glass thicknesses 8, 10 and 12 mm For secured outer areas For toughened safety glass (ESG) For horizontal and vertical glass edging For use in combination with Glass Fittings and Pendulo double-action doors Fixed panel profile with clip-on cover profile design 40 | Modular fixed panel profile systems | Floor springs andglass clamping fi t tings TEC HN ICAL DATA FO R M O D U LAR F I X E D PAN EL PRO FI LE SYSTEMS Product features Profile design 40 Overall depth 30 mm Profile height 40 mm Usable glass thicknesses 8, 10 and 12 mm Installation heights (max.) 4,000 mm Glass pane weight (max.) 150 kg Glass pane width (max.) 2,500 mm Available surfaces Silver-coloured and stainless steel optic anodised Material Aluminium Length (max.) 6,000 mm Burglar-resistant installation of the fitting yes Cover caps Aluminium/Stainless steel Position of the clamping unit in the basic profile variable * without front end caps also for 12 mm PROD U CT S CALE D R AW I N G MO DU LA R FI X E D PANEL PROF ILE WITH CL IP- O N C OVE R P RO FILE DESIG N … 0 SYST E M C OMP O N E N TS Basic profile Basic profile 65 66 Floor springs andglass clamping fit tings | Modular fixed panel profile systems | Fixed panel profile with clip-on cover profile design 40 Clamping units Clamping units Clamping shim for … mm glass thickness Safety set for fanlights and free-hanging glass panes Safety set for fanlights and free-hanging glass Fixed panel profile with clip-on cover profile design 40 | Modular fixed panel profile systems | Floor springs andglass clamping fi t tings Clip-on cover profile design 40 Clip-on cover profile design 40 B End cover caps for profile design 40 Front side cover cap profile design 40, glass thicknesses 8, 10 and 12 mm B = Width (30 mm for glass thicknesses
… TING SYSTEM FOR SLIDING DOORS, END-FOLDING AND CENTRE-FOLDING DOORS B E W E G UN G M I T S YS T EM Photo on page 2: Siegelwerk GmbH Manual sliding door systems GEZE APOLL ROLLER GUIDED SLIDING FITTING SYSTEM CONTENTS GEZE Apoll – The roller guided sliding fitting system for particularly heavy industrial doors Apoll for sliding doors Apoll for folding doors Apoll für centre-folding doors Apoll accessories for end-folding and centre-folding sliding doors Product information for sliding fitting systems
