TS 3000 EC

T-Stop guide rail TS 3000/ 5000 * With opening restrictor and lever

T-Stop guide rail BG
  • Easy to replace with the standard guide rail
  • Saves time as no floor mounted door stopper needs to be installed
  • With screwed slide block
  • Pivot bearing T-Stop
Contact us

T-Stop guide rail TS 3000/ 5000

Application Areas

  • Single leaf doors
  • Installation on hinge side
  • Right and left single-action doors
  • For opening restriction without door stopper

Technical data

T-Stop guide rail TS 3000/ 5000
Length 452.5 mm
Width 33 mm
Height 30 mm
Opening restrictor integrated Yes
Hold-open function Optional

Downloads

Variants & Accessories

Floor-mounted pivot bearing T-stop guide rail
Accessories

Pivot bearing T-Stop

For opening restriction or hold-open of doors without door closer

Product details
GEZE mechanical hold-open unit
Accessories

Mechanical hold-open unit

For standard/T-Stop/Boxer 20.7 mm guide rail

Product details

* Notice about the products displayed

The products mentioned above may vary in form, type, characteristics and function (design, dimensions, availability, approvals, standards etc.) depending on the country. For questions please contact your GEZE contact person or send us an E-Mail .
