Perlan

Perlan 140 Teleskop * Telescopic sliding fitting system for ceiling mounting of timber leaves, consisting of basic components, track and telescopic Perlan set, double-leaf, can be extended to three-leaf

GEZE Perlan 140 telescope outside Accessories Perlan
  • For timber, plastic, and metal leaves
  • For two-leaf or three-leaf systems of up to 140 kg per leaf
  • Can already be used for extremely narrow leaf widths from 475 mm upwards up to leaf widths of max. 1700 mm
  • Pre-assembly of the telescope set on the door leaf allows for comfortable installation
  • Needs 2x basic components, 2x track and 1x telescopic Perlan double leaf set --> Product features
Contact us

Application Areas

  • Space-saving door hardware for large passages
  • Living, office, and conference areas as well as hotels
  • All other product features correspond to the Perlan 140 sliding system

Technical data

Perlan 140 Teleskop
Leaf material Wood
Leaf weight (max.) 140 kg
Number of leaves 2-leaf, 3-leaf
Leaf width (min.) 475 mm
Leaf width (max.) 1700 mm
Track geometry straight
Corrosion protection class 2
Type of installation Ceiling
DIN direction left / right
