Perlan

Perlan 140 glass * Sliding door fitting for glass leaves and ceiling installation

Set Perlan 140 roller sliding system Set Perlan 140 roller sliding system, ID 119336
  • Sliding door fitting for leaf weights of up to 140 kg
  • For glass leaves
  • With one or tow-sided draw-in damper
  • Adjustable height compensation levels out unevenness between the ceiling and the track
  • Precision ball bearings in the roller carriages offer very smooth sliding action
  • Tested for durability in accordance with DIN EN 1527 over 100,000 test cycles
Contact us

Application Areas

  • Frequently used interior sliding doors
  • Living, office, and conference areas as well as hotels
  • Installation of fittings in all visible areas
  • Single and multiple-leaf sliding doors
  • Installation to the ceiling

Technical data

Perlan 140 glass
Leaf material Toughened safety glass (ESG-H), Laminated safety glass (LSG from toughened safety glass)
Leaf weight (max.) 140 kg
Number of leaves 1-leaf
Leaf width (min.) 500 mm
Leaf width (max.) 1640 mm
Leaf height (max.) 3500 mm
Leaf thickness from 8 mm
Leaf thickness to 12.76 mm
Track geometry straight
EN 1670 Corrosion resistance 2 (acc. to EN 1670: Class 0 = none defined, Class 1 = low, Class 2 medium, Class 3 = high, Class 4 = very high, Class 5 = extraordinary)
EN 1527 Continuous function 100,000 test cycles
Type of installation Wall, Ceiling
DIN direction left / right
Clip-on covers Rectangular
Manual operation Yes
Surface anodised
Colour EV1
