MSW with fine-framed panels

MSW sliding panel - fine-framed * Basic element of a movable fine-framed glass partitioning wall

MSW system with fine-framed leaves, Lazienki Kolo Wisly (Public WC in Warsaw) Manual sliding wall systems (MSW) open up, divide, and separate rooms and they adapt flexibly to your particular needs. With the MSW SmartGuide technology, shop fronts can be opened completely and no longer require swing door end panels.
  • Horizontal and vertical profiles for glass framing
  • Toughened safety glass ESG 10 mm flush on one side
  • Insulating glass 22 mm centred applicable
  • Element weight up to 125 kg
  • Dry glazing by means of circumferential glazing gasket
  • Can be combined with all other element types - fine-framed
Contact us

Application Areas

  • Movable framed glass partition walls
  • Internal and protected external area
  • Can be used up to 3000 mm clear height
  • Can be used up to 1500 mm element width
